Getting to Know Your Gas Fire’s Pilot Light and Thermocouple

If you have a gas fire installed in your home, you likely rely on it for cosy warmth and ambience during the cooler months. But do you know what makes your gas fire kick on whenever you flip the switch? Behind the scenes, your gas fire relies on two essential components: the pilot light and the thermocouple. In this post, we'll learn what they are, how they work together, and how to maintain them for safe and reliable operation.

The critical role of pilot lights and thermocouples

The pilot light and thermocouple are crucial parts of your gas fire's ignition system. They work hand-in-hand to detect when you want the fire lit and safely regulate gas flow into the firebox.

Without a pilot light and thermocouple functioning correctly, your gas fire won't turn on when needed. A pilot light provides the initial flame required to ignite the main gas burner. The thermocouple detects the heat from the pilot light, signalling to the gas valve that it's safe to allow more gas into the firebox to create the main flame.

Knowing these components' role in lighting your fire allows you to maintain them and troubleshoot any issues properly. Read on to learn more about what each part does and how they operate as a safety system.

What is a gas fire pilot light?

The pilot light is a small, constant flame inside the firebox near the main burner. When your gas fire is installed and hooked up to the main line, the installer will light the pilot light and adjust it to a precise, steady flame.

This persistent little flame acts as the ignition source to light the main burner whenever you turn on your fire. When you flip the switch or turn the knob to the 'on' position, a valve opens, allowing more gas to flow into the firebox. The pilot light ignites this gas, creating a larger main fire.

Safety features

The pilot light has a couple of essential safety functions:

• It serves as a warning system if the main burner has trouble igniting or staying lit. If other safety devices detect that the main flame didn’t ignite from the pilot light, the gas supply will shut off to prevent a dangerous gas leak.
• It’s always burning, so you have an instant ignition source ready when you need to light the fire – no need for matches.

Design

The pilot light's flame comes from a small tube called a pilot burner. A gas supply line to the main gas control valve connects this. The size of the flame can be adjusted depending on your fire model. A stable, horizontal blue flame around ½" to 1" in height is usually recommended.

The pilot burner is positioned to ignite the main burner outlets. Some pilot lights have a thermocouple probe sitting directly in the pilot flame, while others have the probe slightly above the flame. This allows the thermocouple to detect the pilot flame’s heat and relay the signal to open the gas valve.

What is a gas fire thermocouple?

The thermocouple is a safety device that works with the pilot light to detect when the pilot flame is lit and signals the gas valve to open. It's a simple but essential component that prevents gas flow to the main burner if the pilot light isn't burning.

How it works

A thermocouple consists of two thin metal wires joined together at one end. One wire is made of magnetic material, while the other is made of a non-magnetic metal. A small electrical current is generated when the pilot flame heats the two different metals.

This electrical signal is sent from the thermocouple to the gas valve or an electromagnet that controls gas flow. When the valve detects the electrical current, it opens and allows gas into the main burner tube.

If the pilot light goes out and stops heating the thermocouple, the electrical charge drops, shutting off the gas supply for safety. The thermocouple will continue sending the signal to keep the gas flowing as long as the pilot flame stays lit. But if it stops detecting that heat source, it closes the valve.

Designs

Thermocouples have several designs, but a simple probe is the most common in gas fires. This elongated probe sits either in the pilot flame or near its tip.

More complex thermopile systems have multiple thermocouples bundled together to amplify the electrical charge, but these are not typically common in gas fires.

The gas valve system

The gas valve system manages the fuel supply and flame ignition in a gas fire. This is where the pilot light and thermocouple connect to control gas flow.

How it operates

When you turn your fire on using the switch or remote control, here’s what happens:

1. The switch activates the electromagnet in the gas valve, which is usually closed.
2. The pilot flame heats the thermocouple, generating an electrical charge.
3. This charge maintains current flowing to the electromagnet as long as the pilot stays lit. The electromagnet then pulls open the valve.
4. Gas flows from the supply line through the valve and out the main burner, igniting from the pilot flame.
5. When you turn your fire off, the electromagnet closes the valve and stops the main gas flow. But the pilot flame continues burning.

The thermocouple constantly informs the valve that it's safe to remain open. Without that signal, the valve automatically shuts for safety if the pilot goes out for any reason.

Most fires have a standing pilot system, as described. However, some modern models have an intermittent pilot ignition. For these, the pilot only lights when you turn on the fire, saving energy when unused.

Maintenance

Keeping the valve and its electrical components clear of dust, corrosion, and debris is crucial. Any obstruction can interfere with the valve's timing and sensitivity. Cleaning components and checking for proper operation is advised annually.

Like any other gas-burning appliance in your home, your gas fire needs regular inspection and maintenance to operate safely and efficiently. The pilot light and thermocouple are no exception. Here are some maintenance tips:

• Whenever you use your gas fire, inspect the thermocouple and pilot light burner tube visually. Look for signs of excessive rust, damage, or obstruction from dust and dirt.
• Use compressed air to gently dust the pilot assembly, thermocouple, and valve at least once a year. Buildup here can cause problems.
• When cleaning the firebox, carefully vacuum around the pilot area to remove any dirt, pet hair, lint, etc. Avoid bumping or damaging the pilot tube.
• If your pilot flame appears small, weak, or unstable, contact a professional to adjust it.
• Have your gas fire serviced by a professional Gas-safe engineer annually. They will thoroughly inspect all gas components for proper and safe function.
• If you notice any issues with the pilot or main burner lighting, consider having the thermocouple replaced by a professional every three years or sooner. Old thermocouples deteriorate over time.
• Always turn off the gas valve when cleaning your fireplace or during a service. Never attempt repairs yourself unless you are highly trained.

Troubleshooting issues

Pilot and thermocouple problems can prevent your gas fire from operating normally. Here are some common issues and solutions:

Pilot won’t stay lit: If the pilot flame lights but then goes out when you release the gas control knob, there could be a problem with the thermocouple or valves. Have a technician inspect the components.

Pilot won’t light: If the pilot doesn't light at all, first confirm the gas supply line is fully turned on. If so, the igniter may need service, or there could be blockages in the pilot tube. Try cleaning any dirt or dust. If this doesn’t work, call a professional.

Weak pilot flame: The pilot light flame should burn steadily. If it's low, lazy, or uneven, adjustments may be needed so it's appropriately heating the thermocouple. A Gas-safe engineer can do this for you.

Main burner won’t light: If the pilot stays lit, but the main fire burner won't ignite, the thermocouple signal to the valve may be compromised by dirt, damage, or a failing part. Try cleaning the interior components with compressed air. If this does not work, contact a professional to have a look.

Gas smell: Any odour may signal a dangerous gas leak. Turn off the fireplace and immediately call your gas company or a gas-safe engineer.

By understanding how the pilot light and thermocouple allow your gas fire to operate safely, you can take steps to maintain these crucial parts and resolve issues quickly.

If needed, contact a professional Gas-safe engineer for assistance. With a properly functioning system, your fireplace will provide a cosy ambience and heat for years.
